Lancer 5.000
Lancer 6.500
Lancer 7.500
Lancer 7.500 TH Stainless Steel
Lancer 2.500
Lancer 2.500 Stainless Steel
Lancer 4.500
Lancer 5.000
Lancer 6.500
Lancer 7.500
Lancer 7.500 TH Stainless Steel
Lancer 2.500
Lancer 2.500 Stainless Steel
Lancer 4.500
Slat conveyor
Reinforced modular stainless steel conveyor (optional)
Transmission ratio for low and high doses
Two models of placement funnel
Protection arch for spreading discs
Chute set for central distribution
Central Deflector
Reinforced stainless steel modular conveyor kit
Device for band distribution
Divider and cover for poultry litter
Protection grid
Conveyor speed reduction kit
Stainless steel spreading disc kit
Linea 6.000
Linea 6.000 Canavieiro
Línea bracket for Lancer prior to 1995
| Coupling system | Drawbar |
| Volumetric capacity | 2.50 m³ |
| Recommended maximum load capacity | 3.750 Kg |
| Required power | 70 to 85 cv |
| Spreading width | 6 to 25 m |
| Running gear | Tire/rim 7.50-16 (10 ply) / 5.5 F x 16 |
| PTO rotation | 540 rpm |
| Track width | 1.635 mm |
| Ground clearance under the axle | 340 mm |
| Height of the discs above the ground | 625 mm |
| Height | 1.720 mm |
| Width | 1.840 mm |
| Length | 4.600 mm |
| Approximate empty weight w/tires | 1.170 Kg |
Conveyor belt for distributing organic fertilizer and powdered products (dry and wet).
Reinforced stainless steel modular conveyor belt for applying granular fertilizers and seeds (optional).
Conveyor belt protective deflector, located inside the hopper and positioned transversally to the conveyor belt movement.
Central and side belt speed transmission system equipped with single roller chain gears that allows for three different combinations.
Front and side cardan shaft with protection.
Oil-bath crown and worm gear reducer with fuse pin system.
Two distribution discs with four vanes each, offering five angle adjustment options.
Two hopper models
Distribution of granular fertilizers and similar products
Distribution of powdered products and similar products
The distribution discs are driven by a transmission with shafts and cardan joints.
Front cardan joint with protection.
Oil-bath transmission box.
Removable axle and tandem assembly.
Wheel axle ends with quick-change system.
Deposit made of carbon sheet metal, with side reinforcements to the chassis.
Attach the header to the tractor's drawbar.
Lancer Brochures
Parts Catalog 1
Manual 1
