Tanker 10.000
Tanker 15.000
Tanker 10.000
Tanker 15.000
Collection box: performs the conditioning of the grain, avoiding pressure and friction, protecting the integrity of the grain
Tempered augers
Upper auger mounted on bearings over springs
Gate for inspection, cleaning and discharge into hoppers, located at the lower part of the discharge tube
Hydraulic cylinder kit for Transfer lid
Rear hitch
Bagger
Wheels DW 16-34, DW20-26, DW 20-30
| Coupling system | drawbar |
| Minimum required power | 120 CV |
| PTO rotation | 540 rpm |
| Volumetric capacity | 10.000 L |
| Capacity in bags (soybean) | 125 |
| Discharge capacity (bags/min) | 46 |
| Unloading time for grain | 2'40'' min |
| Discharge tube diameter | 320 mm |
| Discharge height with flow director | 4.025 mm |
| Running gear standard | (without tires): DW 16-30 |
| Track width | 2.150 mm |
| Outer-side width of the tires | 2.734 mm |
| Height with tarpaulin bows | 2.990 mm |
| Length with discharge tube | 4.600 mm |
| Approximate empty weight with tires | 1.475 kg |
Coupled to the captation box, which holds the grains, avoiding pressure and friction, protecting the integrity of the grains.
Powered by a horizontal worm screw, located in the tank's internal base.
With an opening and closing regulation system of the discharge tube flow control, through an external lever positioned and manually operated.
Supporting bearing of the discharge tube's upper worm thread, mounted on coil springs.
The articulation of the discharge tube is made through a hydraulic cylinder, equipped with an exclusive mechanical locking system in the discharge position
Rear horizontal worm gear support bearing, located on the outside of the tank.
For operations that do not require product removal, through the discharge tube, use the lower outlets.
Cover located at the base of the discharge tube, on the left side. Used for inspection and discharge into hoppers.
Drive cardan with torque terminal with fuse pin.
Transmission box in oil bath.
Tank made of carbon steel plate.
Arches for canvas.
Cover located on the left side of the tank, used for discharge into the hopper or regulation of product flow to feed the Transfer 500 (optional), activated manually or by hydraulic cylinder (optional).
Axle tips with quick-change system.
Hub with 8 holes.
Coupling hitch to the tractor's traction bar with a ball joint and 150-mm height adjustment.
