Tanker 10.000
Tanker 10.500
Tanker 10.500 Stainless Steel
Tanker 15.000
Tanker 15.000 Stainless Steel
Tanker 10.000
Tanker 10.500
Tanker 10.500 Stainless Steel
Tanker 15.000
Tanker 15.000 Stainless Steel
Captation box: performs the conditioning of the grains, avoiding pressure and friction, protecting the integrity of the grains
Tempered worm threads
Spring-loaded upper thread
Gates for inspection, cleaning and discharge into hoppers, located at the bottom of the discharge tube and another on the right side of the tank
Canvas Covery Easy Kit
Electromagnetic clutch kit via radio for driving the transmission of the multi-purpose discharge tube
Kit for driving the product flow and discharge tube opening via radio (simple command).
Wheels DW 20-30, DW 21-32, DW 25-26
| Coupling system | Traction bar |
| PTO rotation | 540 rpm |
| Volume capacity | 15.000 L |
| Bag capacity (soybean) | 187 |
| 4.525 mm 1 | |
| Wheelset (tire/wheel) | (Without tires): DW 20-26 |
| Gauge | 3.187 mm 1 |
| Width external side tires | 3.769 mm 1 |
| Height | 3.325 mm 1 |
| Length | 6.255 mm |
| Empty weight with tires | 2.430 Kg |
| observacao | 1 - Mandatory the use of the shim on the floodgate to limit the fertilizer flow. |
Discharge tube diameter (mm): 300.
Discharge height with standard wheelset (mm): 4525.
Grain discharge capacity (bags/min): 40.
Grain discharge time (min): 4’35”.
Granulated fertilizer discharge capacity (Kg/min): 1000.
Granulated fertilizer discharge time (min): 16’.
Comes with a shim to limit the opening of the gate for the fertilizer. 1
Feeding system for gravity.
Two models of discharge nozzles: one nozzle with a canvas for seed discharge and another nozzle with a hose to supply planters.
Coupled to the captation box, which holds the grains, avoiding pressure and friction, protecting the integrity of the grains.
With an opening and closing regulation system of the discharge tube flow control driven by hydraulic cylinder.
The articulation of the discharge tube is made through a hydraulic cylinder, equipped with an exclusive mechanical locking system in the discharge position.
Supporting bearing of the discharge tube's upper worm thread, mounted on coil springs.
For operations that do not require product removal, through the discharge tube, use the lower outlets.
Cover located at the base of the discharge tube, on the left side. Used for inspection and discharge into hoppers.
Gate opening: with shim to limit the opening.
Via cardan driven by tractor PTO 540 rpm (standard).
Via radio by electromagnetic clutch driven by tractor PTO 540 rpm. (optional).
Transmission box in oil bath.
Tank made of removable stainless steel plate.
Arches for canvas.
Cover located on the left side of the tank, used for discharge into the hopper or regulation of product flow to feed the Transfer 700 (optional), activated manually or by hydraulic cylinder (optional).
Hub with 10 holes.
Axle tips with quick-change system.
Coupling hitch to the tractor's traction bar with a ball joint and 150-mm height adjustment.
