Linea 8.000 TM/TH
Linea 6.000
Linea 8.000 TM/TH
Linea 6.000
Precision in the transverse profile
No need for overlapping
Reduces drift
Applies the product in a localized manner
Articulable sides for displacement
| Closed dimensions | 1.530 mm x 2.720 mm x 1.900 mm (HxWxL) |
| Opened dimensions | 1.000 mm x 6.150 mm x 1.150 mm (HxWxL) |
| Distance between holes | 125 mm |
| Hole dimensions lozenge format | 32 x 40 mm |
| Thread Rotation | 405 rpm |
| Thread diameter | 152,3 mm |
| Thread pitch | 120 mm |
| Approximate weight | 390 Kg |
| Useful distribution width | 6.000 mm |
| PTO rotation | 540 rpm |
| observation | 1 ?€“ TM ?€“ Distributors with mechanical transmission. |
Distribution system through worm thread that provides a uniform profile in all its width, not requiring overlapping.
Application rate regulation (kg/ha) through the Lancer's dosing gate.
Equalization of the product flow, realized by means of metering rulers, driven millimeters by handles.
Components in contact with the product to be distributed, made of stainless steel or protected by surface treatment
Lancer 4.500 TM, 6.500 TM e 7.500 TH Inox 1
Lancer Magnu 10.000 TM e TH e 20.000 TM 1
Lancer Magnu 10.000 Plus TM e TH 1
Lancer Multiuso 12.000 TM 1
Lancer Maximus 8.000 e 12.000 TM e TH 1
Brochure Linea
