Tanker Fast 33.000
Tanker Fast 19.000
Tanker Fast 33.000
Tanker Fast 19.000
Discharge capacity of 200 bags per minute.
Capture box for grain conditioning, avoiding pressure and friction, protecting the integrity of the grains
Tempered worm threads
Upper thread bearing on springs
Gates for inspection, cleaning and discharge into hoppers, located at the bottom of the discharge tube and tank.
Wheelset: SB-10
Conveyor belt Wheels: DW 16A-34 - Filipado AG27
Wheelset kit with brake
Canvas Covering easy kit
| Coupling System | Traction bar |
| PTO rotation | 540 rpm |
| Volumetric capacity | 19.000 L |
| Bag capacity (soybean) | 240 |
| Discharge capacity (bags/min) | 200 |
| Discharge time | 1'12'' min |
| Discharge tube diameter | 500 mm |
| Discharge height with flow director | 4.000 mm 1 |
| Standard wheelset (Tire/Wheel) | (Without tires): DW 27A-32 |
| Gauge | 2.532 mm 1 |
| Outer side width of standard tires | 3.298 mm 1 |
| Height with arches for canvas | 3.488 mm 1 |
| Length | 6.574 mm |
| Empty weight with tires | 3.750 Kg |
| observation | 1 - According to the mounted wheelset |
Coupled to the captation box, which packs the grains, avoiding pressure and friction, protecting the integrity of the grains.
Equipped with a flow director, to better conduct the charge in the truck.
Powered by horizontal worm thread, located in the internal base of the tank.
With opening and closing regulation system of the flow control of the discharge tube, through an external lever driven by a hydraulic cylinder.
Support bearing of the discharge tube’s upper worm thread, mounted on coil springs.
The articulation of the discharge tube is done through the hydraulic cylinder, equipped with an exclusive mechanical locking system in the discharge position.
Rear support bearing of the horizontal worm thread, located on the external part of the tank.
For operations that do not require product removal by the discharge tube, use the bottom output.
Cover located at discharge tube base, on the left side. Used for inspection and discharge in hoppers.
Cardan drive, with one free-spin terminal and another torque terminal with fuse pin.
Transmission box in oil bath.
Tank made of removable carbon steel plate.
Arches for canvas.
Cover located under the tank, used for inspection and discharge into hopper, manually operated.
Axle points with quick-change system.
Hub with 10 holes.
Coupling hitch to the tractor traction bar with ball joint and height adjustment with 150 mm variation.
