Cross Belt
Modulated reinforced stainless steel belt (optional)
Transmission ratio for low and high doses
Two models of deposition hopper
Protection arch for distribution discs
Modulated stainless steel reinforced belt kit
Stainless steel distribution disk kit
Linea 6.000
Línea 6.000 Sugarcane
Internal protection grid kit for granulated fertilizers and similar
Internal protection grid kit for limestone and similar
| Coupling system | Traction bar |
| Capacity | 5.00 m³ |
| Maximum charge capacity | 10.000 Kg |
| Required power | 95 to 110 CV |
| Distribution width | 6 to 25 m |
| Wheelsets Tire/Rim | 12.4-24 TM 95 (10 canvas) / W10-24 |
| PTO rotation | 540 rpm |
| Track gauge | 1.900 mm |
| Free span under axle | 470 mm |
| Height of the discs to the ground | 790 mm |
| Height | 2.332 mm |
| Width | 2.225 mm |
| Length | 5.245 mm |
| Approximate empty weight with tires | 2.046 Kg |
Cross belt for distribution of organic fertilizer and powdered products (dry and wet).
Modulated reinforced stainless steel belt for the application of granulated fertilizers and seeds (optional).
Belt deflector protector, located in the internal part of the tank arranged transversally to the belt displacement.
Speed transmission System to the central and side belt track, equipped with single roller chain gears that enable six different combinations.
Front and side cardan with protection.
Reducer type crown and worm shaft in oil bath, with fuse pin system.
Two distribution discs with four vanes each, containing five angular adjustment options.
Two models of deposition hoppers (standard), for specific use in the distribution of granulated fertilizers, powder products, and similar.
Splined transmission system axles for coupling the cardans and gears, that is, without pins and/or keys.
Front cardan with protection.
Transmission box in oil bath.
Dismountable axle and tandem set.
Wheelset axle ends with quick-change system.
Tank made of carbon plate, with lateral reinforcements to the chassis.
Hitching of the header with ball joint to the tractor drawbar.
