Lancer Semea 3.000/5.000
Lancer Semea 3.000/5.000
The only one on the market with a double product flow metering system (normal/fine), for adjusting small and large application rates
Individual and split flow-metering gates, with hydraulic opening control
Spreading discs, flow regulators, vanes and front disc protector made of stainless steel
Special protection system for the seed and the fertilizer particles, through a deflector that interrupts the air channel, forming a protective curtain
Special axle with track width adjustment range of 3.500 mm
Internal protection grid
Pre-germinated rice protection kit
| Coupling system | Drawbar |
| Capacity | 3 m³ / 5 m³ |
| Recommended maximum load capacity | 3.000 / 5.000 Kg 1 |
| Adjustable spreading width | 12, 18, 24 e 36 2 |
| PTO rotation | 540 rpm |
| Height of the discs above the ground | 1.130 mm |
| Height | 2.412 / 2.852 mm |
| Width with standard axle | 3.010 mm |
| Width with optional axle | 3.810 mm |
| Adjustable wheel track width standard axle | 1.800 mm à 2.700 mm |
| Adjustable wheel track width axle optional | 1.800 mm à 3.500 mm |
| Length | 3.880 mm |
| Approximate empty weight w/tires | 1.690 / 1.705 kg |
| note | 1 - The maximum recommended load capacity is limited to the mechanical strength of the chassis structure and especially the tank. |
| note | 2 - The spreading width adjustment is done by changing the vanes, which come in three different sizes (lengths). |
Tank made of rotomolded polyethylene, attachable to the chassis.
The tank is fixed to the chassis by two eyebolts, which provide efficient fastening, easy dismounting of the tank, and safe lifting of the Lancer.
Protective screens of the flow metering system and tank bases, made of injected nylon.
Protection caps made of injected polyethylene, attached to the sieves and positioned on the agitators, provide continuous flow and prevent grinding of the product to be distributed.
Distribution discs, flow regulators, vanes, and front protector of the discs made of stainless steel plate
Double product flow dosing system (thin/normal), allows the regulation of small and large application rates.
Individual and biparted product flow dosage gates, with opening control through graduated rods and adjustable stops, made of injected nylon, which provide an accurate flow.
Drive for opening and closing of the flow dosage gates, through hydraulic cylinders.
Protection curtains (deflector plates), positioned under the flow dosage gates, avoid the impact and rebound of the product particles on the discs.
Centrifugal-type distribution system, composed of two concave discs with four adjustable vanes in four different angular positions.
Three sizes (length) of vanes that allow three configurations of mounting on each disc and determine four different distribution widths.
Via Cardan 540 rpm.
Transmission box in oil bath.
Coupling of the header with ball joint to the tractor traction bar.
