Lancer 6.500
Lancer 7.500 TH Inox
Lancer 4.500
Lancer 6.500
Lancer 7.500 TH Inox
Lancer 4.500
Cross belt
Modulated reinforced stainless steel belt (optional)
Transmission ratio for low and high doses
Two models of deposition hopper
Protection arch for distribution discs
Rail set for central distribution
Central Deflector
Injector Device
Modulated reinforced stainless steel belt kit
Device for stripe distribution
Divider and cover for poultry litter
Protection grid
Belt speed reduction kit
Stainless steel distribution disc kit
Linea 6.000
Linea 6.000 Sugarcane
Support for Lancer less than 1995
| Coupling system | Traction bar |
| Capacity | 2.50 m³ |
| Maximum charge capacity with lime (1500kg/m3) | 4.500 Kg |
| Required power | 70 to 85 HP |
| Distribution width | 6 to 25 m |
| Wheelsets | Tire/Rim 11L15 (10 canvas) / 8LB x15 |
| PTO rotation | 540 rpm |
| Track gauge | 1.701 mm |
| Free span under axle | 340 mm |
| Height of discs to ground | 625 mm |
| Height | 1.773 mm |
| Width | 1.780 mm |
| Length | 4.245 mm |
| Approximate empty weight with tires | 910 kg |
Cross-belt for distribution of organic fertilizer and powdered products (dry and wet).
Modulated reinforced stainless steel belt for the application of granulated fertilizers and seeds (optional).
Belt deflector protector, located in the internal part of the tank arranged transversally to the belt displacement.
Speed transmission System to the central and side belt track, equipped with single roller chain gears that enable three different combinations.
Front and side cardan with protection.
Reducer type crown and worm shaft in oil bath, with fuse pin system.
Two distribution discs with four vanes each, containing five angular adjustment options.
Two models of deposition hoppers:
The drive of the distribution discs is done through transmission with axles and cardans.
Front cardan with protection.
Transmission box in oil bath.
Simple wheelset.
Wheelset axle ends with quick-change system.
Tank made of carbon plate, with lateral reinforcements to the chassis.
Hitching of the header to the tractor drawbar.
