Lancer Magnu 20.000
Lancer Magnu 10.000
Lancer Magnu 10.000 Stainless Steel
Lancer Magnu 10.000 TH
Lancer Magnu 10.000 TH Stainless Steel
Lancer Magnu 10.000 Plus Stainless Steel
Lancer Magnu 10.000 Plus TH
Lancer Magnu 20.000
Lancer Magnu 10.000
Lancer Magnu 10.000 Stainless Steel
Lancer Magnu 10.000 TH
Lancer Magnu 10.000 TH Stainless Steel
Lancer Magnu 10.000 Plus Stainless Steel
Lancer Magnu 10.000 Plus TH
Protection arch for spreading discs
Reinforced modular stainless steel conveyor
Protection grid
Linea 6.000
Linea 6.000 Canavieiro
Stainless steel spreading disc kit
Running gear kit sugarcane track width (2.800 mm)
Internal protection grid kit for granulated fertilizers and similar
Internal protection grid kit for limestone and similar
| Coupling system | Drawbar |
| Volumetric Capacity | 10.00 m³ |
| Maximum recommended capacity | 15.000 kg |
| Spreading width | 6 à 25 m |
| Wheels Tire/rim front | 18.4-30 TM 95 (12 ply) / DW 16-30 |
| Wheels Tire/rim rear | 23.1-26 MB 39 (14 ply) / DW 20-26 |
| PTO rotation | 540 rpm |
| Track width | 2.552 mm |
| Ground clearance under the axle | 450 mm |
| Height of the discs above the ground | 896 mm |
| Height | 2.696 mm |
| Width | 3.197 mm |
| Length | 7.170 mm |
| Approximate empty weight w/tires | 4.040 kg |
-png-1744290149507.png)
-png-1744290149989.png)
-png-1744290149466.png)
-png-1744290149926.png)
Two distribution discs with four vanes each, containing five angular adjustment options.
Two models of deposition hopper:
Splined transmission system axles for coupling the cardans and gears, that is, without pins and/or keys.
Front cardan with protection.
Transmission box in oil bath.
Dismountable axle and tandem set.
Wheelset axle ends with quick-change system
Tank made of carbon plate, with lateral reinforcements to the chassis.
Hitching of the header with ball joint to the tractor drawbar.
