Unloading capacity of 150 bags per minute.
Tempered augers.
Upper auger mounted on bearings over springs.
Product flow adjustment covers, positioned at the front of the body with wooden guides.
Front Tube for better visibility when unloading grain and for maneuvers.
Easy Tarping Kit
Multipurpose Discharge Tube
Nozzle Sleeve-Hose Multipurpose Tube
Axle with Brake
23.1-26 tire DW 20x26 rim (Standart)
18.4-34 tire DW 16x34 rim
23.1-30 tire DW 20x30 rim
18.4-30 tire DW 16x30 rim
24.5-32 tire DW 21x32 rim
28.1-26 tire DW 25X26 rim
| Coupling system | DRAWBAR |
| PTO rotation | 540 rpm |
| Volumetric capacity | 17.000 L |
| Capacity in bags (soybean) | 212 |
| Grain discharge tube diameter | 370 mm |
| Discharge capacity (bags/min) | 150 |
| Estimated unloading time | 1’25” min |
| Multipurpose discharge tube diameter | 370 mm (carbon steel) |
| Grain discharge height | 4.430 mm |
| Track width | 2.358 mm |
| Outer-side width of the tires (with 18.4-30 tires) | 2.840 mm |
| Total width with tube mounted | 3.190 mm |
| Total height | 3.618 mm |
| Height on the left side of the machine | 3.538 mm |
| Height on the right side of the machine | 3.336 mm |
| Total length | 6.480 mm |
| Empty weight w/ tires | 3.838 Kg |
| Min. required power | 110 à 130 CV |
| Optional kit | EASY TARPING SYSTEM |
Gravity feed system;
Product flow control covers, positioned at the front of the tank with wooden guides;
Cylinder for opening and closing the flow control cover (gate), positioned above it. Directly activates the cover;
Support bearing for the upper worm screw of the discharge pipe, mounted under coil springs;
Hardened worm screws;
Ladder positioned at the rear of the tank with hinge for transport;
Wheels, header, side reinforcements, and discharge pipe are removable;
Axle ends with quick-change system.
Cardan shaft driven by tractor PTO 540/1,000 rpm;
Oil-bath transmission box;
Headlight for lighting the discharge pipe, providing better nighttime visibility.
Coupling attachment to the tractor's drawbar with ball joint.
Hub with 10 holes;
Axle ends with quick-change system;
Axle with two wheels.
Storage compartment made of removable carbon steel sheet.
Arches for canvas;
Rear light: hazard warning light, directional indicator, brake light, and reverse light.
